The popular image of chemical engineering is one of enormous distillation towers and high-pressure reaction vessels with attendant staff in hard-hats and goggles. But, there is much more to chemical engineering than large industrial plant. As one example, chemical engineers from the University of Cambridge have teamed up with molecular biologists at Aston University and together they are using EPSRC funding to open up new frontiers in their art. Their work with artificial proteins is allowing them to capture specific fragments of DNA from complex mixtures and produce highly pure agents for gene therapy.
Unlike the more
familiar chromosomes, which are long strands of DNA, plasmids are small
circles of DNA found in bacteria, which are separate from its main genetic
material. By adding a gene of interest to an isolated plasmid and
reinserting it back into a bacterium, molecular biologists can exploit the
ability of bacteria to replicate rapidly to make copies of the new gene.
Administering these engineered plasmids to a patient with a genetic disorder
could replace a missing or damaged gene with a working copy. However, as
chemical engineers know only too well, purity is a limiting factor in many
processes.
There are several methods for cleaning up plasmids for gene therapy
applications. However, these tend to be labour-intensive require several
demanding steps to avoid leaving potential contaminants, such as toxins from
the host bacteria. They also yield only relatively small amounts of plasmid
material. "Plasmid DNA is a potentially attractive route for delivering
genes," explains Professor Nigel Slater, who is working with Dr Sid Ghose on
the Cambridge side of the collaboration. "But manufacturing would benefit
from a simple process that yields a very pure preparation of the plasmid
DNA. The bacterial cell contains many contaminants, such as toxic
lipopolysaccharide (LPS), toxins from the cell wall."
Slater and his colleagues at Cambridge are working with molecular biologist
Dr Anna Hine and Dr Richard Darby at Aston University to find a simple way
to obtain pure plasmid DNA rapidly and with few process steps. The key to
their new approach is to exploit proteins which bind exclusively to specific
target regions, or 'sequences', within the plasmid DNA. These protein groups
are attached at one end to a solid support material, such as beads of the
polymer gel agarose, then as the bacterial cell mixture passes over them the
other end of the protein unit latches on to the plasmid DNA only, ensnaring
it while other compounds, including the toxins are simply washed off. The
plasmid DNA can then be released in pure form from the beads.
Slater and Hine have worked together using two approaches to this problem.
In the first, they constructed a protein in which a finger-like protein
unit, known as a zinc-finger transcription factor is coupled to the enzyme
GST (glutathione-S-transferase). The zinc-finger latches on to the target
recognition DNA sequence in the modified plasmid DNA. The researchers can
then capture this protein-DNA complex on an agarose bead carrying
glutathione groups. In the second, simpler approach, the researchers
replaced the zinc-finger with another protein known as LacI. LacI binds
strongly to a target DNA sequence, known as the <I>lac</I> operator. As they
explain, the first approach was a good model system to establish the
feasibility of the programme and subsequently, to establish technical
parameters, but the protein binds so tightly to the DNA, that it may be
difficult to remove at the end of the process. The second approach is far
more suitable for actual plasmid purification because the strong binding is
entirely reversible and after purification, the DNA can be released from the
protein at will using a solution of the sugar molecule allolactose , or one
of its synthetic analogues. These compounds change the shape of the LacI
protein, which shakes off the pure plasmid, while the LacI protein is left
behind, still bound to the solid support.
Hine's team addressed the molecular biology aspects of the project on a
small scale and Slater's group tackled the engineering aspects of the
project, such as how to scale the work up for commercial viability. They
have found that although they can successfully extract plasmids with the
zinc finger approach, recovery of the purified material is relatively
difficult. However, having d emonstrated proof of principle, they turned to
the LacI method and have now developed several techniques for producing
highly pure DNA in a simple affinity process. The LacI system works in a
packed bed chromatography system. In this system, a glass column is packed
with silica gel which absorbs different materials at different rates as a
mixture is flushed through with solvent so th ey can be tapped off one after
the other. This type of chromatography works on pure, clarified and filtered
solutions. The results demonstrate the possibility of using the affinity
system in a scalable process and allowing the plasmid DNA to be extracted in
a single step ready for storage.
"This is a technique called affinity chromatography and is widely used to
purify other biological substances such as antibodies," says Slater. "It is
a very attractive and powerful technique but there is no equivalent process
for DNA which can be generically operated at a production scale to make
grams of DNA."
The team has now further developed their approach into an expanded bed
absorption (EBA) system. EBA systems are commercially available and commonly
used for separating out components in blood and other biological mixtures.
The EBA system offers process advantage by allowing mixtures to be processed
that have not been clarified so they can be loaded directly on to a
chromatography column in which the adsorbent material is suspended in the
flow stream. This, the researchers explain, allows the cell debris and other
materials to be flushed through quickly. The EBA system therefore works more
effectively than the packed bed approach allowing the team to extract
plasmid DNA directly from the bacterial cells.
"From an engineering viewpoint the study has extended fundamental scale-up
principles to large macromolecular products," Slater told Newsline,
"bringing together the design of chromatography materials, considerations of
mass transfer and fluid flow and sophisticated process analysis."
"This is the first demonstration of protein affinity purification procedures
for DNA manufacture," adds Slater, "The procedures we've been working on are
largely restricted to DNA but some of the problems we've faced, for example
how to adsorb very large macromolecules on to beads designed for the
adsorption of small proteins, are generic." He adds that there is crossover
with work he and his colleagues are doing on affinity purification of
viruses and synthetic nanoparticles for drug delivery."
This article by David Bradley originally appeared in EPSRC Newsline, Issue 31, p10 (849kb pdf)
